HOLOSUN Aiming Laser LS117R / G / IR
The LS117R and LS117G are a 7075 Aluminum bodied class IIIA visible green and rot laser aiming device. The LS117IR is a class 2M IR laser aiming device. Features include a quick release picatinny rail mount, remote pressure switch, and IP67 water resistance.
Product information "HOLOSUN Aiming Laser LS117R / G / IR"
In the Box
- QD Release Mount
- T10 L Key
- AA Battery (LS117R and LS117IR)
- CR2 Battery (LS117G)
- Remote Cable Switch
- User Manual
Tech & Features
- Collimated Red / Green / IR Laser Pointer
- Remote Cable Switch
- Quick Release Mount
- IP67 Waterproof
Main Data
- Product Nr. LS117R (Red laser pointer) 78003231
- Product Nr. LS117G (Green laser pointer) 78003132
- Product Nr. LS117IR (IR laser pointer) 78002531
- Laser & Illuminator Type Single Laser
Technical Parameters
- Lifetime > 10.000 h
- Operating Temperature -20℃~51℃
- Storage Temperature -20℃~65℃
Optical Parameters
- Beam Shape Dot
- Optical Power 0.7 mW
- Wavelength rot 635 nm
- Wavelength grün 520 nm
- Wavelength IR Laser 830 nm
- Laser class laser pointer red/green 3R
- Laser class IR laser / illuminator 2M
- Optics glass lens AR coated
- Focus collimated
Electrical Parameters
- Operating Voltage 3 V DC
- ALT Battery (LS117R/IR) AA
- ALT Battery (LS117G) CR2
Mechanical Parameters
- Size 25x40x24 mm
- Weight 138g
- Material 6061 T6 Aluminium
- Housing Color black
- Protection Class IP67
